Or check it to let Windows turn off USB ports to save power. If you want USB ports to keep supplying power in sleep mode, just uncheck “ Allow the computer to turn off this device to save power“.
#Usb switch on off serial
#Usb switch on off Pc
Also provide connectors for CON1 through CON3.įeel interested? Check out other electronics projects.Keyboard or mouse not working after your PC wake up from sleep? When you’re charging your phone through an USB port, putting your PC into sleep mode will turn off the power to USB ports, and your phone will stop charging. Enclose the PCB in a small box in such a way that you can connect it to TV’s and STB’s USB ports. Construction and testingĪ single side PCB for the automatic USB controlled power switch is shown in Fig.
#Usb switch on off tv
When you switch off the TV using the remote control, both the TV and STB will get switched off. Press switch S1 momentarily to activate the TV LED and STB. The second is, when you use sleep timer mode of the TV, you can switch on the LED TV without pressing switch S1 again, if the time lapses before you sleep.įinally, working of the circuit is simple. The first is to protect the gadgets from harmful power surges that may occur while switching on using switch S1. There are two benefits of using the timing capacitor. 3: Component layout of the PCBĭownload PCB and component layout PDFs: click here After the capacitor has discharged, the complete system gets switched off. If you wish to keep it on for longer, use higher-value capacitor C1. T1 stays on for a predetermined time (about 100 seconds) only due to the charged timing capacitor C1. So 5V voltage available to the optocoupler stops. When you switch off the TV using its remote control, power that was available at its USB port connected across CON4 also stops. 2: PCB of the automatic USB controlled power switch Timing capacitor C1 gets positive supply voltage through diode D1 and it remains charged until mains power of the LED TV is disconnected. When the LED TV (connected across CON2) and the STB (connected across CON3) get 230V AC mains power, USB port of the TV (connected across CON4) gets power to enable IC1. When transistor T1 gets base-bias voltage, it conducts and relay RL1 energises to provide 230V AC mains to power sockets CON2 and CON3, which are used to connect an LED TV and STB, respectively. When switch S1 is pressed, it allows positive voltage to timing capacitor C1 and the power to go through the connected zener diode ZD1 and resistor R3 to the base of transistor T1. 1: Circuit diagram of the automatic USB controlled power switchĢ30V AC mains power supply connector CON1 is connected between n/o contacts of relay RL1 and neutral line N. USB-A extender cables are used to connect the USB ports of the TV and of the STB to the circuit. It is built around optocoupler PC817 (IC1), transistor BC547 (T1), 12V 1C/O relay (RL1), six rectifier diodes 1N4007 (D1 through D6) and a few other components. USB controlled power switch circuitĬircuit diagram of the automatic USB controlled power switch is shown in Fig. Besides, it protects the devices from harmful initial surges when power comes back after a power failure. This drawback can be overcome using this circuit. When you switch off the power of the TV using a remote control or sleep timer in the TV, the switched-mode power supply (SMPS) of the TV continues to draw a small amount of power from mains and the STB does not get switched off. Generally, mains power for TV and STB are derived from a common switchboard. Here we present a USB controlled power switch circuit that can control the mains power of an LED TV and a DTH set-top box (STB). You can use the USB port as an automatic switch to control devices powered by mains. Almost all electronic gadgets now come with one or more USB ports.
